Master Lock MCM614 Smart Keyed Push Button Mortise Lock
The Connected Master Lock MCM614 Mortise Lock is a smart keypad upgrade for traditional mortise locks that offers keyless access for high-traffic businesses, like retail stores and office buildings. Provide your staff with seamless, keyless entry and added peace of mind with a lock built for enhanced high security.
Built-in High Security: The durable, pick-resistant lock meets high security standards for greater resistance to forced attempts, and the lock will alarm if forcibly removed.
Ultimate Control: Create up to 500 unique codes for staff and maintenance crews with the flexibility to use the key if needed.
Auto-Lock: Ensure the door is locked every time staff closes for the day.
Design Variety: Connected Mortise Locks are available in push button or touchscreen designs that are key-free or keyed with deadbolt locks. Choose from a variety of wear-resistant finish options for long-term durability.
Remote Access: Lock doors remotely — access anywhere, anytime.
Flexible Connectivity: Connect through Z-Wave Plus or Zigbee and manage with partner apps to expand your smart building and alarm solutions.
Specifications:
Deadbolt Specifications: Fits standard residential door
Power Requirements: 6AA alkaline batteries (included) with optional hardwire input for 9V DC external power; 9V battery power backup on keypad.
Door Thickness: 1-3/4", 2", 2-1/4"
Strike: 124mm x 32mm x 2.5mm with lip length standard
Face Bore: 2-3/4" x 1-1/8"
Edge Bore: 2-1/8"
Latch: 1"
Backset: 3/4" Throw Latch, 1" Deadbolt (optional), 2-3/4" (70MM) standard bracket
Handing: Field Reversible
Warranty: 2-year electrical; 3-year mechanical and finish
